Can ToneCooling design a custom liquid cold plate?

Yes. ToneCooling designs custom liquid cold plates around the customer heat load, coolant, flow rate, pressure drop limit, mechanical envelope, and production requirement.

What information is needed for a quote?

Please provide heat load, coolant type, flow rate, maximum pressure drop, inlet temperature, target case temperature, mechanical envelope, mounting requirements, material preference, quantity, and drawings if available.

Copper or aluminum, which is better?

Copper improves heat spreading for high heat flux zones. Aluminum can reduce weight and cost when the thermal target, coolant chemistry, corrosion control, and pressure requirement allow it.

How do you control pressure drop?

Pressure drop is controlled through channel width, path length, manifold balance, parallel flow layout, port size, and the specified flow rate.

Can you support microchannel cold plates?

Yes. Microchannel designs can be reviewed when the heat flux, pressure drop budget, manufacturability, cleaning process, and reliability requirements are suitable.

Do you provide DFM review before production?

Yes. ToneCooling reviews sealing, port design, flatness, tolerances, leakage risk, coolant compatibility, and process selection before prototype or batch production.

What leak testing is performed?

Leak testing is specified around the working pressure, coolant, joining process, and customer standard. Final pressure and acceptance criteria are confirmed during DFM.

Can you support prototype and OEM production?

Yes. ToneCooling supports prototype builds, engineering iteration, pilot runs, and OEM batch production for custom thermal management parts.

Server CPU Liquid Cold Plate | Intel Xeon RFQ Review

Intel LGA4677 Liquid Cold Plate RFQ Review

ToneCooling reviews drawing-based LGA4677 server CPU liquid cold plate projects for direct-to-chip cooling. The RFQ review focuses on socket footprint, keep-out zone, module envelope, coolant path, flow rate, pressure-drop limit, port direction and validation requirements before quotation.

Send the official motherboard or cold plate drawing, heat load, coolant, inlet temperature, target flow rate, allowable pressure drop, hose routing constraint, material preference, prototype quantity and annual demand.

Request LGA4677 Cold Plate RFQ Review View LGA4677 RFQ Inputs

Intel LGA4677 server CPU liquid cold plate layout review

Socket and module envelopeConfirm footprint, mounting points, stack height, keep-out zones and service access.

Coolant path and pressure dropDefine coolant, inlet temperature, flow target and allowable pump pressure budget.

Validation scopeDefine leak test, pressure test, flatness, cleanliness and report requirements.

LGA4677 Cold Plate Engineering Data to Confirm

Target platform	Intel Xeon LGA4677 server CPU liquid cooling projects. Final compatibility depends on the customer-approved mechanical drawing.
Cold plate route	Copper or aluminium route is reviewed from heat load, coolant, pressure-drop limit, corrosion risk, weight and cost target.
Manufacturing process	CNC machined, vacuum brazed, FSW or other process route is selected after channel geometry and material route review.
Required RFQ inputs	Drawing or CAD file, heat-source map, coolant, flow rate, pressure-drop target, envelope, port orientation, quantity and project stage.
Validation scope	Leak test, pressure test, flow-resistance check, flatness, cleanliness and documentation requirements are confirmed before quotation.
Manufacturing site	Huizhou, Guangdong, China. Regional teams may support communication and project coordination where applicable.

Engineering Support Pages for LGA4677 RFQs

Use these pages to prepare a cleaner RFQ package before asking for quotation. Each card links to the detailed engineering input page.

Intel LGA4677 RFQ InputsPlatform drawing, heat load, coolant, flow rate and pressure-drop inputs.

Server CPU Cold Plate RFQ ChecklistDrawing, heat load, coolant, pressure-drop and validation inputs.

CPU cold plate pressure drop and flow rate review

Pressure Drop and Flow Rate ReviewPrepare flow rate, coolant, inlet temperature and pump pressure budget.

server CPU cold plate port layout and hose routing

Port Layout and Hose RoutingReview fitting direction, hose clearance, bend radius and service access.

Leak, Pressure and Cleanliness ValidationDefine leak test, pressure test, cleanliness and documentation scope.

server liquid cooling module envelope review

Server Module Envelope Review1U, 2U and custom chassis envelope, tube route and service access.

LGA4677 Cold Plate RFQ Checklist

Official socket, motherboard or cold plate mechanical drawing
Heat load, heat-source map and contact area
Coolant type, inlet temperature and corrosion constraints
Target flow rate and pressure-drop limit
Port direction, connector requirement, hose route and bend radius
Leak, pressure, cleanliness, flatness and documentation requirements
Prototype quantity, annual demand and project stage

Official Platform Reference

Use Intel Xeon processor information only as platform context. ToneCooling quotation still depends on the customer-approved drawing, thermal requirement and validation scope.

LGA4677 Liquid Cold Plate FAQ

Can ToneCooling manufacture a LGA4677 liquid cold plate from a drawing?
Yes. ToneCooling reviews drawing-based server CPU cold plate projects and confirms manufacturability, channel route, material route, port layout and validation scope before quotation.

Do you guarantee compatibility with every LGA4677 server board?
No unsupported compatibility guarantee is made from the platform name alone. Compatibility must be confirmed from the official mechanical drawing, keep-out zone and mounting envelope.

What information is needed before quotation?
Send drawing or CAD file, heat load, coolant, flow rate, pressure-drop limit, envelope, port orientation, quantity and validation requirements.

Can the port direction and hose layout be customized?
Yes, port direction and hose routing can be reviewed against service access, bend radius, rack layout and pressure-drop budget.

Where are these cold plates manufactured?
Manufacturing is based in Huizhou, Guangdong, China under ToneCooling's manufacturing system.
